Amphenol C016 30D006 110 12 Bullet Connector 6+PE Pins Straight

Name: Amphenol C016 30D006 110 12 Bullet Connector 6+PE Pins Straight
Brand: Amphenol
Price: 10.96 GBP
Availability: InStock

Standard range

Order Code:

11-2767

Brand: Amphenol MPN: C016 30D006 110 12 EAN-13: 2050001709622

RoHS Compliant
Country of Origin: Germany
Free UK shipping available
View Full Product Range (35)

Inc VAT

Qty	Unit Price (Ex VAT)
1+	£10.96

Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT

46 in stock, despatched in 4 working days

Product Details
Product Range
Data Sheets
Quick Quote

Amphenol's C016 30D006 110 12 bullet connector is a straight, round connector featuring 6 pins plus PE. This robust connector from the Ecomate series is designed for reliable and secure connections in electrical applications. It is commonly used in industrial and commercial environments for efficient and safe power and signal transmission.

Type	Bullet connector
Cable Ø (max.)	12.5mm
Cable Ø range	6 - 12.5 mm
Cable Ø up to	6mm
Case material	Polyamide 6.6
Connection angle	180°
Connector type	Connector, straight
Cross-section range	0.75 mm² (max)
Factory colour	Black
IP rating	IP67 (when locked)
Leading contact (PE)	Yes
Manufacturer part #	C016 30D006 110 12
max. cross section	0.75mm²
Max. temperature	+125°C
Min. temperature	-40°C
Misc Attribute	C016 30D006 110 12
Nominal current	10A
Nominal current - rounded value	10A
Nominal voltage	250V
Number of pins	6
Seal	Screw-type locking
Series	C016
Total no. of pins	6 + PE
