Connfly DS1020-03ST1D Socket Housing PCB 3 Pins 2.54mm 1 piece

Name: Connfly DS1020-03ST1D Socket Housing PCB 3 Pins 2.54mm 1 piece
Brand: Connfly
Price: 0.358 GBP
Availability: InStock

Standard range

Order Code:

08-7942

Brand: Connfly MPN: DS1020-03ST1D EAN-13: 2050003634083

RoHS Compliant
Country of Origin: China
Free UK shipping available
View Full Product Range (4)

Inc VAT

Qty	Unit Price (Ex VAT)
1+	£0.358

Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT

1,850 in stock, despatched in 4 working days

Product Details
Product Range
Data Sheets
Quick Quote

Connfly's DS1020-03ST1D is a socket housing designed for PCB applications. It features three pins with a contact spacing of 2.54 mm, providing a compact and reliable connection. This component is typically used in electronic devices where secure, small-scale interconnections are essential.

Board contact surface	Tin plated
Case material	Thermoplastic UL94V-O
Connection	Print
Connector contact surface	Tin plated
Connector orientation	Perpendicular (to the PCB)
Connector system	wire-to-board
Connector type	Socket, vertical vertical
Contact material	Copper alloy
CS	2.54mm
Dim	(L x W x H) 15.62 x 4.50 x 6.75 mm
Factory colour	Black
Height	6.75mm
Industrial packaging	No
Insulation material	Thermoplastic UL94V-O
Length	15.62mm
Manufacturer part #	DS1020-03ST1D
Misc Attribute	DS1020-03ST1D
No. of rows	1
Nominal current	3A
Nominal current - rounded value	3A
Pin Ø	0.60mm
Pin shape	Planar
Pins per row	3
RoHS-compliant	Yes
Total number of pins	3
Type	Socket housing PCB
Width	4.50mm
