TracoPower TMR 4-2411 DC/DC Converter 5V 0.8A 4W 1 pc

TracoPower
Standard range
Order Code:

07-8299

Brand: TracoPower MPN: TMR 4-2411
Qty Was Unit Price (Ex VAT)
1+ £12.72 £11.89
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
15 in stock, despatched in 4 working days

The TracoPower TMR 4-2411 is a DC/DC converter that delivers 5 V DC at 0.8 A with a power output of 4 W. This compact, high-efficiency unit is designed for PCB mount applications, featuring solder lugs for secure integration. Typical uses include powering electronic circuits and PCB equipment in industrial and consumer electronics.
Type DC/DC converter
Connection Solder pins
Dim (L x W x H) 21.8 x 9.3 x 15.2 mm
Efficiency (max.) 81%
Height 15.2mm
Input voltage (max.) 36.0V DC
Insulation voltage 1600V DC
Length 21.8mm
Max. output current 0.8A
Min. input voltage 18.0V DC
Misc Attribute 1 TMR 4-2411
Misc Attribute 2 closed
No. of outputs 1
Operating temperature (max.) 70°C
Operating temperature (min.) -40°C
Operating voltage 5 V
Output current (max.) - rounded 800mA
Output current (min.) 0mA
Output voltage (max.) 5V DC
Output voltage (min.) 5V DC
Output voltages +5.0V DC
Power 4W
Weight 4.8g
Width 9.3mm
