TracoPower TMR 4-2422 DC/DC Converter 4W 0.16A Compact Design 1pc

TracoPower
Standard range
Order Code:

07-8301

Brand: TracoPower MPN: TMR 4-2422
Qty Unit Price (Ex VAT)
1+ £12.19
5+ £12.12
10+ £12.01
25+ £11.94
50+ £11.47
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
10 in stock, despatched in 4 working days

TracoPower's TMR 4-2422 is a PCB mount DC/DC converter designed to deliver 4 W of power with a current output of 0.16 A. It features solder lugs for easy installation, making it ideal for PCB equipping and compact power supply applications. This converter is suitable for use in diverse printed circuit board power supply units.
Type DC/DC converter
Connection Solder pins
Dim (L x W x H) 21.8 x 9.3 x 15.2 mm
Efficiency (max.) 86%
Height 15.2mm
Input voltage (max.) 36.0V DC
Insulation voltage 1600V DC
Length 21.8mm
Max. output current 0.16A
Min. input voltage 18.0V DC
Misc Attribute 1 TMR 4-2422
Misc Attribute 2 closed
No. of outputs 2
Operating temperature (max.) 70°C
Operating temperature (min.) -40°C
Operating voltage 12 V
Output current (max.) - rounded 160mA
Output current (min.) 0mA
Power 4W
Weight 4.8g
Width 9.3mm
