Counttec S2K90 Timer DIN Rail Multifunction Weekly & Holiday Settings

Name: Counttec S2K90 Timer DIN Rail Multifunction Weekly & Holiday Settings
Brand: Counttec
Price: 40.67 GBP
Availability: InStock

Standard range

Order Code:

08-8374

Brand: Counttec MPN: S2K90 EAN-13: 4026576020903

RoHS Compliant
Country of Origin: China
Free UK shipping available

Inc VAT

Qty	Unit Price (Ex VAT)
1+	£40.67

Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT

13 in stock, despatched in 4 working days

Product Details
Data Sheets
Quick Quote

Counttec's multifunction relay, the S2K90 ESRD-TPD2, is a versatile DIN rail mount timer with configurable week, weekday, and holiday settings. It excels in automating lighting and controlling electrical circuits efficiently. Typical applications include staircase light timing and general time delay relay functions.

Type	DIN rail mount timer
Connection	Screw terminal
Contact type	2 change-overs
Depth	36mm
Dim	(W x H x D) 64 x 90 x 36 mm
Height	90mm
IP rating	IP20
Max. operating voltage	264V
Max. switching capacity	384W
Max. temperature	+55°C
Min. operating voltage	24V
Min. temperature	-20°C
Misc Attribute	ESRD-TPD2
No. of switching intervals	2
Operating voltage	24 - 264 V
Power reserve	10Years
RoHS-compliant	Yes
Switching current (max.)	16A
Switching voltage (max.)	250V AC
Width	64mm
