StandexMeder 9282661054 MK28-1B-500W Reed Switch 175V 1A 10W

StandexMeder Electronics
Standard range
Order Code:

10-6909

Brand: StandexMeder Electronics MPN: 9282661054 EAN-13: 2050003801034
Qty Unit Price (Ex VAT)
1+ £2.97
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
97 in stock, despatched in 4 working days

The StandexMeder Electronics MK28-1B-500W is a reed switch designed for applications requiring a 1 breaker capacity with up to 175 V DC or 175 V AC. It can handle a current of 1 A and a power rating of 10 W. Typical uses include door contacts and sensors for security systems or position detection.
Type Reed switch
Cable length 0.50m
Connection Open end cable
Contact type 1 breaker
Dim (L x W x H) 25.4 x 19.5 x 6.35 mm
Enclosure material Nylon
Height 6.35mm
Length 25.4mm
Max. switching capacity 10W
Max. temperature 105°C
Min. temperature -40°C
Misc Attribute MK28-1B-500W
Switching current (max.) 1A
Water activity 15 - 20
Water activity (max.) 20
Water activity (min.) 15
Width 19.5mm
