Self Electronics SLD15-700IL-ES SLD15 Series LED Driver 15.4W 700mA Dimmable

Self Electronics
Order Code:

10-5658

Brand: Self Electronics MPN: SLD15-700IL-ES EAN-13: 4021087047432
Qty Unit Price (Ex VAT)
1+ £14.87
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
42 in stock, despatched in 4 working days

The Self Electronics SLD15-700IL-ES LED driver features a constant current output of 15.4 W and 700 mA, suitable for dimmable LED applications. Designed with overvoltage and surge protection, it ensures durability and reliability. This LED driver is ideal for powering LED strips and other LED lighting solutions.
Type LED driver
Connection Screw terminal
Dim (L x W x H) 85.3 x 41 x 22 mm
Height 22mm
Input voltage (max.) 264V AC
IP rating IP20
Length 85.3mm
Max. output current 700mA
Max. power 15.4W
Max. temperature 50°C
Min. input voltage 198V AC
Min. temperature -25°C
Misc Attribute 1 Constant current
Misc Attribute 2 Pulsed
No. of inputs 1
No. of outputs 1
Operating voltage 230V AC
Output current (max.) - rounded 700mA
Output voltage (max.) 22V DC
Output voltage (min.) 9V DC
Power range 15.4 W (max)
Protection class II
Test mark SELV, CE, ENEC (pending)
Width 41mm
