Self Electronics SLT75-24VL-E LED Driver 75W 24V DC for Flammable Surfaces

Self Electronics
Order Code:

10-5723

Brand: Self Electronics MPN: SLT75-24VL-E EAN-13: 4021087039055
Qty Unit Price (Ex VAT)
1+ £31.49
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
17 in stock, despatched in 4 working days

The Self Electronics SLT75-24VL-E LED driver delivers a constant voltage of 24 V DC with a power capacity of 75 W and a current of 3.1 A, making it suitable for use on flammable surfaces and furniture installations. Key features include surge protection, overvoltage protection, and a non-dimmable configuration. This LED driver is typically used in powering LED lighting systems, such as LED strips and other compatible LED applications.
Type LED driver
Connection Screw terminal
Dim (L x W x H) 185 x 60 x 31 mm
Height 31mm
Input voltage (max.) 264V AC
Inputs 1
IP rating IP20
Length 185mm
Max. output current 3.1A
Max. power 75W
Max. temperature +50°C
Min. input voltage 198V AC
Min. temperature -20°C
Misc Attribute 1 Constant voltage
Misc Attribute 2 Pulsed
No. of inputs 1
No. of outputs 1
Operating voltage 230V AC
Output current (max.) - rounded 3.1A
Output voltage (max.) 24V DC
Output voltage (min.) 24V DC
Power range 75 W (max)
Protection class II
Test mark MM, CE, SELV, CCC
Width 60mm
