Self SLT60-48VFG-UN LED Driver 30W 48V DC Non-Dimmable, Surge Protection

Self Electronics
Order Code:

10-5713

Brand: Self Electronics MPN: SLT60-48VFG-UN EAN-13: 4021087052849
Qty Unit Price (Ex VAT)
1+ £32.54
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
16 in stock, despatched in 4 working days

The Self Electronics SLT60-48VFG-UN LED driver provides a constant voltage of 48 V DC and is rated at 30 watts. It is suitable for installation on flammable surfaces and approved for use on furniture, featuring surge protection and overvoltage protection. This LED driver is ideal for powering LED strips and other low-voltage LED applications.
Type LED driver
Connection Screw terminal
Dim (L x W x H) 298 x 30 x 16 mm
Height 16mm
Input voltage (max.) 264V AC
IP rating IP20
Length 298mm
Max. output current 1250mA
Max. power 30W
Max. temperature +45°C
Min. input voltage 108V AC
Min. temperature -20°C
Misc Attribute 1 Constant voltage
Misc Attribute 2 Pulsed
No. of inputs 1
No. of outputs 1
Operating voltage 230V AC
Output current (max.) - rounded 1.25A
Output current (min.) 0A
Output voltage (max.) 48V DC
Power range 30 W (max)
Protection class II
Test mark CE · MM · SELV · UL
Width 30mm
