TruConnect 213989 7 Way 10A Black Interlocking Terminal Block 5mm

Image Representative of Range

TruConnect 213989 7 Way 10A Black Interlocking Terminal Block 5mm

TruConnect
Standard range
Order Code:

21-3989

Brand: TruConnect MPN: 213989 EAN-13: 5053556021390
Qty Unit Price (Ex VAT)
1+ £0.622
10+ £0.480
50+ £0.407
100+ £0.352
250+ £0.311
500+ £0.278
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
100 in stock, despatched same dayAdditional quantity lead time 5 months

Vertical mounting, wire protector, interlocking moulded terminal block with 7 poles, 5mm pitch.


  • Vertical orientation
  • Interlocking (2-way and 3-way)
  • Wire protector clamp
  • 22 to14AWG (1.5mm²)
  • Slotted screws
  • Rated voltage: 300V
  • Rated current: 10A
  • Moulded housing in black flame retardant PBT
  • Screws: M2.5, zinc plated steel
  • Pin header: tin plated brass
  • Stainless steel wire guard
  • UL approved
Colour Black
Current Rating 10A
Mounting Direction Vertical
Mounting Type Through Hole
No. of Ways 7
Pitch 5mm
Voltage Rating 300V
Wire Gauge 1.5mm²
Wire Gauge (AWG) 22 to 14AWG
Wire Termination Screw, Wire Protector
