Self Electronics SLD15-350IL-ES SLD15 Series LED Driver 14.7W 350mA Dimmable

Self Electronics
Order Code:

10-5656

Brand: Self Electronics MPN: SLD15-350IL-ES EAN-13: 4021087047418
Qty Unit Price (Ex VAT)
1+ £14.06
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
76 in stock, despatched in 4 working days

The Self Electronics SLD15-350IL-ES LED driver is a dimmable, constant current device providing 14.7 W and 350 mA with an output voltage range of 24 - 42 V DC. It features overvoltage and surge protection, making it suitable for LED strip applications. This LED power supply unit is ideal for indoor lighting systems where reliable power control is necessary.
Type LED driver
Connection Screw terminal
Dim (L x W x H) 85.3 x 41 x 22 mm
Height 22mm
Input voltage (max.) 264V AC
IP rating IP20
Length 85.3mm
Max. output current 350mA
Max. power 14.7W
Max. temperature 50°C
Min. input voltage 198V AC
Min. temperature -25°C
Misc Attribute 1 Constant current
Misc Attribute 2 Pulsed
No. of inputs 1
No. of outputs 1
Operating voltage 230V AC
Output current (max.) - rounded 350mA
Output voltage (max.) 42V DC
Output voltage (min.) 24V DC
Power range 14.7 W (max)
Protection class II
Test mark SELV, CE, ENEC (pending)
Width 41mm
