Self Electronics SLD15-350IL-ES SLD15 Series LED Driver 14.7W 350mA Dimmable

The Self Electronics SLD15-350IL-ES LED driver is a dimmable, constant current device providing 14.7 W and 350 mA with an output voltage range of 24 - 42 V DC. It features overvoltage and surge protection, making it suitable for LED strip applications. This LED power supply unit is ideal for indoor lighting systems where reliable power control is necessary.

Type	LED driver
Output Voltage	24V DC
Max Output Power	14.7W
Output Current	350mA
Input Voltage	264V AC
Colour	Grey, Blue
Connection	Screw terminal
Dimensions	(L x W x H) 85.3 x 41 x 22 mm
Height	22mm
IP Rating	IP20
Length	85.3mm
Max. output current	350mA
Maximum Temperature	50°C
Min. temperature	-25°C
Minimum Input Volage	198V AC
Misc Attribute 1	Constant current
Misc Attribute 2	Pulsed
Number of Inputs	1
Number of Outputs	1
Protection Class	II
Test mark	SELV, CE, ENEC (pending)
Weight	95g
Width	41mm
