Self Electronics SLD15-500IL-ES LED Driver, 15W, 500mA, 17-30V DC, Dimmable

Self Electronics
Order Code:

10-5657

Brand: Self Electronics MPN: SLD15-500IL-ES EAN-13: 4021087047425
Qty Unit Price (Ex VAT)
1+ £14.61
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
10 in stock, despatched in 4 working days

The Self Electronics SLD15-500IL-ES LED driver provides a constant current output of 500 mA with a power rating of 15 W, supporting voltage ranges from 17 to 30 V DC. This dimmable driver is equipped with overvoltage and surge protection, ensuring reliable performance in varied conditions. It is typically used for powering LED strips and other LED applications where stable and safe operation is crucial.
Type LED driver
Connection Screw terminal
Dim (L x W x H) 85.3 x 41 x 22 mm
Height 22mm
Input voltage (max.) 264V AC
IP rating IP20
Length 85.3mm
Max. output current 500mA
Max. power 15W
Max. temperature 50°C
Min. input voltage 198V AC
Min. temperature -25°C
Misc Attribute 1 Constant current
Misc Attribute 2 Pulsed
No. of inputs 1
No. of outputs 1
Operating voltage 230V AC
Output current (max.) - rounded 500mA
Output voltage (max.) 30V DC
Output voltage (min.) 17V DC
Power range 15 W (max)
Protection class II
Test mark SELV, CE, ENEC (pending)
Width 41mm
