Self Electronics SLD30-500IL-ES LED Driver Constant Current Dimmable 30W 500mA

Self Electronics
Order Code:

10-5664

Brand: Self Electronics MPN: SLD30-500IL-ES EAN-13: 4021087047296
Qty Unit Price (Ex VAT)
1+ £20.23
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
32 in stock, despatched in 4 working days

The Self Electronics SLD30-500IL-ES LED driver offers a constant current output of 500 mA with a power rating of 30 W and an operating voltage range of 30 - 60 V DC. This LED driver is dimmable, suitable for use on flammable surfaces, and features surge and overvoltage protection. It is ideal for powering LED lighting installations and strip lights in residential and commercial environments.
Type LED driver
Connection Screw terminal
Dim (L x W x H) 165 x 40 x 30 mm
Height 30mm
Input voltage (max.) 264V AC
IP rating IP20
Length 165mm
Max. output current 500mA
Max. power 30W
Max. temperature 40°C
Min. input voltage 198V AC
Min. temperature -20°C
Misc Attribute Constant current
No. of inputs 1
No. of outputs 1
Operating current 160mA
Operating voltage 230V AC
Output current (max.) - rounded 500mA
Output voltage (max.) 60V DC
Output voltage (min.) 30V DC
Power (min.) 15W
Power range 15 up to 30 W
Protection class II
Test mark Getaktet
Width 40mm
