Self Electronics SLT30-24VFC-UN SLT30 LED Driver 30W, 24V, Non-dimmable, IP67

Self Electronics
Order Code:

10-5691

Brand: Self Electronics MPN: SLT30-24VFC-UN EAN-13: 4021087047180
Qty Unit Price (Ex VAT)
1+ £30.20
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
4 in stock, despatched in 4 working days

The Self Electronics SLT30-24VFC-UN LED driver is a constant voltage power supply unit that delivers 30 W and 24 V DC with a current range of 0 to 1.25 A. It features surge protection and is suitable for installation on flammable surfaces but is not dimmable. This LED driver is ideal for powering LED strips and other low-voltage lighting applications.
Type LED driver
Connection Open end cable
Dim (L x W x H) 275 x 30 x 16.5 mm
Height 16.5mm
Input voltage (max.) 264V AC
IP rating IP67
Length 275mm
Max. output current 1.25A
Max. power 30W
Max. temperature 50°C
Min. input voltage 108V AC
Min. temperature -20°C
Misc Attribute Constant voltage
No. of inputs 1
No. of outputs 1
Operating current 350mA
Output current (max.) - rounded 1.25A
Output current (min.) 0A
Output voltage (max.) 24V DC
Power range 30 W (max)
Protection class I
Width 30mm
