Self Electronics SLT6-500IL-4 LED Driver 6W 500mA 3-12V DC PFC Surge Protected

Self Electronics
Order Code:

10-5717

Brand: Self Electronics MPN: SLT6-500IL-4 EAN-13: 4021087039161
Qty Unit Price (Ex VAT)
1+ £9.76
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
94 in stock, despatched in 4 working days

The Self Electronics SLT6-500IL-4 is an LED driver providing a constant current of 500 mA at 6 W, with an output range of 3 to 12 V DC. It features a PFC circuit, surge protection, and is suitable for use on flammable surfaces. This LED driver is typically used in LED strip lighting applications.
Type LED driver
Connection Screw terminal
Dim (L x W x H) 68 x 35 x 21 mm
Factory colour White
Height 21mm
Input voltage (max.) 264V AC
IP rating IP20
Length 68mm
Max. output current 500mA
Max. power 6W
Max. temperature 50°C
Min. input voltage 90V AC
Min. temperature -20°C
Misc Attribute Constant current
No. of inputs 1
No. of outputs 1
Operating current 200mA
Output current (max.) - rounded 500mA
Output voltage (max.) 12V DC
Output voltage (min.) 3V DC
Power range 6 W (max)
Protection class II
Width 35mm
