Epcos B72220P3461K101 460V 445J 20mm Metal Oxide Leaded Varistor
Standard range
Order Code:
Brand:
Epcos
MPN: B72220P3461K101 EAN-13: 2050001355423 51-2936
- RoHS Compliant
- Country of Origin: China
- Free UK shipping available
- View Full Product Range (12)
| Qty | Unit Price (Ex VAT) |
|---|---|
| 1+ | £1.59 |
| 50+ | £1.57 |
Price per unit Ex VAT
100 in stock, despatched in 4 working days
A Ø20mm metal oxide disk varistor with an operating voltage of 460V AC. The device is a voltage-dependent resistor whose resistance decreases as voltage increases. When connected in parallel with the component or circuit requiring protection the varistor forms a low-resistance shunt, preventing any rise in surge overvoltage. The varistor is a proven protective device due to its application flexibility and high reliability.
- Clamp voltage 1240V @ IC 100A
- Optimum overvoltage and transient suppression protection
- High resistance at low voltages and low resistance at high voltages
- Tolerance 10%
- Radial leaded
- Epoxy resin coated
- Multiple pulse handling capability
- Also known as Transient Voltage Surge Suppressors (TVSS)
- UL, CSA, VDE, IEC approved
| Case Style | Leaded disk |
|---|---|
| Clamping Voltage | 1240V |
| Size (Ø or L x W) | 20mm |
| Varistor Voltage | 750V |
| Voltage Rating AC | 460V |
| Voltage Rating DC | 615V |
