Signal Construct SMFP30H4289 30mm 230VAC IP67 Blue LED Indicator Lamp
Standard range
Order Code:
Brand:
Signal Construct
MPN: SMFP30H4289 EAN-13: 2050001261083 50-3041
- RoHS Compliant
- Country of Origin: Germany
- Free UK shipping available
- View Full Product Range (3)
| Qty | Unit Price (Ex VAT) |
|---|---|
| 1+ | £12.90 |
Price per unit Ex VAT
A 230V AC/DC blue LED panel indicator that is part of a series that are visually aligned so that the colours give the same impression of brightness. The lamp has an IP67 rated M30 screw-mounting body constructed from chrome plated brass and the lens has a frosted, slimline appearance that optimises on/off contrast.
- 10:1 Pulse mode
- Supplied with nut, washer, sealing ring/sealing disk
- 230V Version supplied with protection sleeve
- Connection via solder tabs
- Second tab for common conductor allows mounting of several indicators
- M30 Body for mounting in a ø30 +0.2mm cut out
- Lifetime 50,000 hours
| Bezel | N/A |
|---|---|
| Colour | Blue |
| Current | 4.5mA |
| Intensity | 250mcd |
| Size | 20mm |
| View Angle | 150° |
| Voltage | 230V |
